Adept Lynx Platform User's Guide, Rev D
Page 32 of 126
Chapter 2: Setup
with the floor plate, all of which will keep the docking station from moving when the platform
docks. Both the wall bracket and floor plate are included with each docking station.
CAUTION: It is very important that the docking station be mounted
with one of these methods, or the platform will simply move the dock-
ing station when it tries to dock, rather than docking successfully.
For all mounting methods:
l
Locate the docking station near an AC outlet with 1 - 2 meters (3.25 - 6.5 ft)of clear
space in front to ease the platform’s maneuvers, especially automated ones, onto the
docking station.
l
The top of the docking station foot is spring-loaded, and lifts off of the bottom of the foot
slightly to accommodate variations in the floor surface. The weight of the Lynx platform
will push the top of the foot down.
Requirements
l
100 to 240 VAC, 50 to 60 Hz, 8 A
The station's power converter automatically detects the source voltage.
l
Ambient operating temperature: 5° to 40° C (41° to 104° F)
l
5 to 95% humidity, non-condensing
Wall Bracket Mount
1.
Attach the docking station mounting bracket to a wall, with the bottom edge of the
bracket 98 ± 20 mm (3.8 ± 0.8 in.) above the floor, using user-supplied anchors and
screws. There is leeway, so you can adjust the height a little bit.
Refer to the following figure:
