Adleepower BL2-104 - Motor Dimensions; Wires Colors

5-2 Motor dimensions
AM-60~370
Unit : mm
12
Wires colors : U(red), V(white), W(black).
No. P M∮ S∮ N∮ T LA LB L1 L2 AD A B1 B2
OUTPUT SHAFT END
ED Q E D∮ GA F
1
90 104 8.5 83 2.5 8
100 128 161
109 27 61 33
20 25 28
12 13.5 4
2
115 147 180
25 29 32
3
14 16 54 170 202 235
5 185 217 250
□
