4. Specification
7
The varnished copper wire is F class insulation.
AM-60~370 motor has magnet brake option. The brake torque is 25Kg-cm
(21.6in-lb) and BL driver offers 24VDC to control it directly.
※ ∮
※ ∮
±
Ω
Ω
Rated Power W 60 90 120 180 250 370
Motor No.
AM-60
L/M
AM-90
L/M/H
AM-120
L/M/H
AM-180
L/M/H
AM-250
L/M/H
AM-370
L/M/H
Drive No. BL2-101 BL2-101 BL2-102 BL2-102 BL2-104 BL2-104
Input Voltage 220V 10% 1ψ
Input Frequency HZ 50 / 60
Rated input current 0.7 1.1 1.5 2.1 2.9 3.6
Motor Phase 3ψ
Rated Torque Kg-cm
(in-lb)
2.9/2.0
(2.5/1.7)
4.4/2.9/1.5
(3.8/2.5/1.3)
5.8/3.9/2.0
(5.0/3.4/1.7)
8.8/5.8/2.9
(7.6/5.0/2.5)
12.0/8.1/4.0
(10.4/7.0/3.5)
18.0/12.0/6.0
(15.6/10.4/5.2)
Rated Speed RPM L/M/H : 2000 / 3000 / 6000
Max. Efficiency % > 80 > 80 > 80 > 80 > 80 > 80
Max. Output W 180 220 280 330 450 600
Max. Torque Kg-cm
(in-lb)
12.0/6.0
(10.4/5.2)
15.0/9.0/5.5
(13.0/7.8/4.8)
18.0/12.0/8.0
(15.6/10.4/6.9)
27.0/18.0/10.5
(23.4/15.6/9.1)
36.0/24.0/13.0
(31.2/20.8/11.3)
54.0/36.0/20.0
(46.8/31.2/17.3)
Variable Speed Range
RPM
L :150~2000 M :150~3000 H :300~6000
Acc. Dec. Time 0.1 ~ 600.0 Sec
Speed
regulation
Load ±1% Below (0~Rated Torque at rated speed)
Voltage ±1% Below (Source voltage± 10% at rated speed No Load)
Temperature ±1% Below (-10~45 / 14~113 at rated speed No Load)
℃ ℉
Motor Insulation/
Max. Working TEMP.
B Class ( 130 /266 ) / Max. 100 /212
※ ℃ ℉ ℃ ℉
Type of control Rectangular wave PWM
Speed command
1. Built-in potentiometer
2. External Potentiometer 2 k
≧
3. 0~5VDC, 0~10VDC, 4~20mA control
4.RS485
Operation
1. Pannel : CW
、CCW、Key
2. Terminal : Type of input
：Photocoupler, input impedance 2.2 k /
CW
、CCW、Common (4.5 ~ 5VDC)
3. Communication : RS485
Output signal
Open collect output, External use condition DC48V
、10mA below
SPEED OUT
、Fault relay A/B
Protection
Any phenomenons as below will come to stop output alarm signal will be output and the
motor.
Over load
：Motor over temperature protection.
Over heat
：Power modular over heat shut down itself.
Lost phase
：Motor signals are abnormal, due to motor cables was broken or
discounector.
Phase to phase short circuit.
Motor enclosure type IP40
Motor figure No. 1 1 2 3 4 5 4(M/H)
BL Driver figure No. 10 10 10 10 10 10
Motor Weight Kg
(lb)
2.1/2.1
(1.8/1.8)
2.4/2.4/2.4
(2.1/2.1/2.1)
2.6/2.5/2.5
(2.3/2.2/2.2)
2.9/2.7/2.7
(2.5/2.3/2.3)
4.0/3.8/3.7
(3.5/3.3/3.2)
4.5/4.0/4.0
(3.9/3.5/3.5)
BL Driver Weight Kg
(lb)
1.1
(1.0)
1.1
(1.0)
1.1
(1.0)
1.1
(1.0)
1.1
(1.0)
1.1
(1.0)
