Adleepower BL2-104 - Page 10

±
Ω
Ω
8
Rated Power W 750 1000 1500 2200
Motor No.
AM-750M/H
CM-750L/M/HX
AM-1000M/H
AM-1500M/H
CM-1500L/M/HX
AM-2200M/H
CM-2200L/M/HX
Drive No. BL2-107 BL2-115 BL2-115 BL2-122
Input Voltage 220V 10% 1ψ
Input Frequency HZ 50 / 60
Rated input current 7.55 10 13.4 18.6
Motor Phase 3ψ
Rated Torque Kg-cm
(in-lb)
AM:24.4/12.2
(21.1/10.6)
CM:36.6/24.4/9.1
(31.7/21.1/7.9)
AM:32.5/16.2
(28.2/14.0)
AM:48.8/24.4
(42.3/21.1)
CM:73.2/48.8/18.3
(63.4/42.3/15.9)
AM:73.2/36.6
(63.4/31.7)
CM:109.8/73.2/26.8
(95.1/63.4/23.2)
Rated Speed RPM L/M/H/HX:2000/3000/6000/9999
Max. Efficiency % > 85 > 85 > 85 > 85
Max. Output W 1600 2300 3000 4000
Max. Torque Kg-cm
(in-lb)
AM:48.8/24.4
(42.3/21.1)
CM:73.2/48.8/18.2
(63.4/42.3/15.8)
AM:65/32.4
(56.3/28.1)
AM:97.6/48.8
(84.6/42.3)
CM:146.4/97.6/36.6
(126.9/84.6/31.7)
AM:146.4/73.2
(126.9/63.4)
CM:210/146.4/53.6
(182/126.9/46.4)
Variable Speed Range
RPM
L:150~2000 M:150~3000 H:300~6000 HX:300~9999
Acc. Dec. Time 0.1 ~ 600.0 Sec
Speed
regulation
Load ±1% Below (0~Rated Torque at rated speed)
Voltage ±1% Below (Source voltage± 10% at rated speed No Load)
Temperature ±1% Below (-10~45 / 14~113 at rated speed No Load)
℃ ℉
Motor Insulation/
Max. Working TEMP.
B Class ( 130 /266 ) / Max. 100 /212
※ ℃ ℉ ℃ ℉
Type of control Rectangular wave PWM
Speed command
1. Built-in potentiometer
2. External Potentiometer 2 k
≧
3. 0~5VDC, 0~10VDC, 4~20mA control
4. RS485
Operation
1. Pannel : CW
、CCW、Key
2. Terminal : Type of input：Photocoupler, input impedance 2.2 k /
CW、CCW、Common (4.5 ~ 5VDC)
3. Communication : RS485
Output signal
Open collect output, External use condition DC48V
、10mA below
SPEED OUT、Fault relay A/B
Protection
Any phenomenons as below will come to stop output alarm signal will be output and
the motor.
Over load
：Motor over temperature protection.
Over heat：Power modular over heat shut down itself.
Lost phase：Motor signals are abnormal, due to motor cables was broken or
discounector.
Phase to phase short circuit.
Motor enclosure type L:IP54 M/ H/HX:IP40
Motor figure No.
AM:6
CM:A/A/D
AM:7
AM:8
CM:B/B/E
AM:9
CM:C/C/F
BL Driver figure No 10 11 11 11
Motor Weight Kg
(lb)
AM:8.0/7.8
(6.9/6.8)
CM:11.0/11.0/14.2
(9.5/9.5/12.3)
AM:9.4/8.7
(8.1/7.5)
AM:11.0/9.7
(9.5/8.4)
CM:14.0/14.0/15.3
(12.0/12.0/13.2)
AM:13.2/16.5
(11.4/14.3)
CM:15.6/15.6/16.5
(13.5/13.5/14.3)
BL Driver Weight Kg
(lb)
1.1
(1.0)
1.3
(1.1)
1.3
(1.1)
13
(1.1)
