Rated Power W 370 750 1000 1500 2200
Motor No. AM-370L/M/H
AM-750M/H
CM-750L/M/HX
AM-1000M/H
AM-1500M/H
CM-1500L/M/HX
AM-2200M/H
CM-2200L/M/HX
Drive No. BL4-304 BL4-307
BL4-315
BL4-315 BL4-322
Input Voltage 380/440V 10% 3ψ
Input Frequency HZ 50 / 60
Rated input current 1.4 2.2 3.0 3.5 5.0
Motor Phase 3ψ
Rated Torque Kg-cm
(in-lb)
AM:18.0/12.0/6.0
(15.6/10.4/5.2)
AM:24.4/12.2
(21.1/10.6)
CM:36.6/24.4/9.1
(31.7/21.1/7.9)
AM:32.5/16.2
(28.2/14.0)
AM:48.8/24.4
(42.3/21.1)
CM:73.2/48.8/18.3
(63.4/42.3/15.9)
AM:73.2/36.5
(63.4/31.6)
CM:109.8/73.2/26.8
(95.2/63.4/23.2)
Rated Speed RPM L/M/H/HX:2000/3000/6000/9999
Max. Efficiency % > 85 > 85 > 85 > 85 > 85
Max. Output W 600 1600 2300 3000 4000
Max. Torque Kg-cm
(in-lb)
AM:54/36/20
(46.8/31.2/17.3)
AM:48.8/24.4
(42.3/21.1)
CM:73.2/48.8/18.2
(63.4/42.3/15.8)
AM:65/32.4
(56.3/28.1)
AM:97.6/48.8
(84.6/42.3)
CM:146.4/97.6/36.6
(126.9/84.6/31.7)
AM:146.4/73.2
(126.9/63.4)
CM:210/146.4/53.6
(182/126.9/46.4)
Variable Speed Range
RPM
L:150~2000 M:150~3000 H:300~6000 HX:300~9999
Acc. Dec. Time 0.1 ~ 600.0 Sec
Speed
regulation
Load ±1% Below (0~Rated Torque at rated speed)
Voltage ±1% Below (Source voltage± 10% at rated speed No Load)
Temperature ±1% Below (-10~45 / 14~113 at rated speed No Load)
℃ ℉
Motor Insulation/
Max. Working TEMP.
B Class ( 130 /266 ) / Max. 100 /212
※ ℃ ℉ ℃ ℉
Type of control Rectangular wave PWM
Speed command
1. Built-in potentiometer
2. External Potentiometer 2 k
≧
3. 0~5VDC, 0~10VDC, 4~20mA control
4. RS485
Operation
1. Pannel : CW
、
CCW
、
Key
2. Terminal : Type of input
：
Photocoupler, input impedance 2.2 k /
CW
、
CCW
、
Common (4.5 ~ 5VDC)
3. Communication : RS485
Output signal
Open collect output, External use condition DC48V
、
10mA below
SPEED OUT
、
Fault relay A/B
Protection
Any phenomenons as below will come to stop output alarm signal will be output and the motor.
Over load
：
Motor over temperature protection.
Over heat
：
Power modular over heat shut down itself.
Lost phase
：
Motor signals are abnormal, due to motor cables was broken or discounector.
Phase to phase short circuit.
Motor enclosure type L/M/H:IP40 L:IP54 M/H/HX:IP40
Motor figure No. 5 4(M/H)
AM:6
CM:A/A/D
AM:7
AM:8
CM:B/B/E
AM:9
CM:C/C/F
BL Driver figure No 10 11 11 11 11
Motor Weight Kg
(lb)
AM:4.5/4.5/4.0
(3.9/3.9/3.5)
AM:8.0/7.8
(6.9/6.8)
M:11/11/14.2
(9.5/9.5/12.3)
AM:9.4/8.7
(8.1/7.5)
AM:11/9.7
(9.5/8.4)
CM:14/14/15.3
(12.1/12.1/13.3)
AM:13.2/16.5
(11.4/14.3)
CM:15.6/15.6/16.5
(13.5/13.5/14.3)
BL Driver Weight Kg
(lb)
1.1
(1.0)
1.3
(1.1)
1.3
(1.1)
1.3
(1.1)
1.3
(1.1)
