8-4 Parameter description
Command mode
CD02
0 : Terminal command in close loop control.
1 : Panel or F306 command in close loop control. (Default
value)
2 : Panel or communicator command in close loop control.
3 : Speed command by RS485 and operate command by termi-
nal in close loop control.
4 : Terminal command in open loop control.
5 : Panel or F306 command in open loop control.
6 : Panel or communicator command in open loop control.
7 : Speed command by RS485 and operate command by termi-
nal in open loop control.
Note :New setting needs to be effected by reset driver (turn off
and turn on power)
33
Setting Range 0 ~ 7
Default value 1
Parameter lock
CD00
Setting Range 0 ~ 9999
Default value 0
0 : Lock.
1 : Unlock.
Motor RPM &
pole selection
CD01
Setting Range 0 ~ 4
Default value As model
0 : 2000 RPM (8 poles).
1 : 3000 RPM (8 poles).
2 : 6000 RPM (4 poles).
3 : 5000 RPM (8 poles).
4 : 9999 Rpm (4 poles).
Note : 1. Reset driver to effect this new parameter setting.
2. This parameter is set at factory. Do not reset if unnec-
essary.
