Setting Range 0 ~ 1
Default value 1
0 : Rush run to stop.
1 : Stop with deceleration time. (Default value)
2 : Free run to stop
Brake mode
CD03
34
Maximum speed
limit
CD04
0 5V(10V)
VOLT(CMD)
2500
3000
RPM
Ex. CD04=2500
Note : This parameter does not work in open loop control.
Minimum speed
limit
CD05
Ex. CD05=300
To get better close loop control performance, the L/M series
need to set over 150RPM and the H/HX series need to set over
300RPM. Please note, the L/M series cannot work at 1~129RPM
and the H/HX series cannot work at 1~259RPM.
Note : This parameter does not work in open loop control.
0 5V(10V)
VOLT(CMD)
150
300
RPM
Setting Range
0 ~ 6000 /
0 ~ 9999
Default value 0
Setting Range
130 ~ 6000 /
260 ~ 9999
Default value
2000(L) / 3000(M)
/ 6000(H) /9999(HX)
