Adleepower BL2-104 - Data Format

40
Transmission
fault treatment
CD23
0 : Alarm and keep operation.
1 : Alarm and decelerate to stop.
2 : Alarm and free run to stop.
3 : No alarm and keep operation.
Setting Range 0 ~ 3
Default value 3
Communicator
protocol
CD24
A. Data format
0 : 8,N,1 RTU (1 start bit+8 data bits+1 stop bit)
8,N,1 RTU(10bits)(character frame in hexadecimal)
1 : 8,N,2 RTU (1 start bit+8 data bits+2 stop bit)
8,N,2 RTU(11bits)(character frame in hexadecimal)
2 : 8,E,1 RTU (1 start bit+8 data bits+1 Even bit+1 stop bit)
8,E,1 RTU(11bits)(character frame in hexadecimal)
3 : 8,O,1 RTU (1 start bit+8 data bits+1 Odd bit+1 stop bit)
8,O,1 RTU(11bits)(character frame in hexadecimal)
Start bit 0 1 2 3 4 5 6 7 Stop bit
Start bit 0 1 2 3 4 5 6 7 Stop bit Stop bit
Start bit 0 1 2 3 4 5 6 7
Even
parity
Stop bit
Start bit 0 1 2 3 4 5 6 7
Odd
parity
Stop bit
Setting Range 0 ~ 7
Default value 4
