66
2. Hall sensor and F306 remote operator extension cable
A-0000-F306G3
F306 Remote operator
E-092A-010200
1 meter extension cable
E-092A-030200
3 meter extension cable
E-092A-050200
5 meter extension cable
E-PEAA-8P8C02
Extension connector
67
