3.9.7 View - Panel
The View Panel Option provides three items to view diagnostic on the panel.
[Panel Information]
LOCAL-HARDWARE SOFTWARE
NETWORK-HARDWARE
Press the  buttons to highlight the required menu option and then press the ✔ button to select it.
 Local hardware provides information on the circuits of this panel.
 Network hardware provides information on the circuits of other panels / nodes on the network.
 Software provides information on the operating software of this panel and its optional interface cards.
3.9.7.1 Software
[Software]
PANEL DISPLAY LOOP CARDS
NETWORK PSU PERIPHERAL
PRINTER
Panel Software:
[Software]
PROGRAM ID : MX5000-050-04
CHECKSUM : 92879016
Other Software:
Select the other options and the display shows the software version incorporated into these circuit cards /
functions and the hardware build variant. A number of peripheral modules may be installed (up to 32) – press
the  buttons to scroll through the list if required.
[Software]
ADRS.CARD TYPE VERSION BUILD
1 Display Card 1.03 00
If there are no devices installed of the type selected, the display shows:
[Software]
ADRS.CARD TYPE VERSION BUILD
NO DEVICES
