1.2 Cautions and Warnings
BEFORE INSTALLATION – Refer To the Ratings shown on the label
inside the product and to the ‘Specifications Chart’ in this document.
Please read this manual carefully. If you are unclear on any point DO
NOT proceed. Contact the manufacturer or supplier for clarification and
guidance.
Only Trained service personnel should undertake the Installation,
Programming and Maintenance of this equipment.
This product has been designed to comply with the requirements of the
Low Voltage Safety and the EMC Directives. Failure to follow the
installation instructions may compromise its adherence to these
standards.
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
This equipment is constructed with static sensitive components.
Observe anti-static precautions at all times when handling printed
circuit boards. Wear an anti-static earth strap connected to panel
enclosure earth point. Before installing or removing any printed circuit
boards remove all sources of power (mains and battery).
1.3 Description
This manual covers the use and operation of the 5000, 5000V & 5000N Series Fire Alarm Control Panels. Refer
to the Installation and Commissioning Manual (Document No. 680-165) for details of how to install and program
the panel.
All panel models are available in a range of enclosure sizes and with a range of alternative optional features.
1.3.1 5000 Series
The 5100 is a Single Loop, Analogue Addressable Fire Alarm Control Panel.
The 5200 is a Two Loop, Analogue Addressable Fire Alarm Control Panel.
The 5400 is a Multiple Loop, Analogue Addressable Fire Alarm Control Panel with provision for up to four loops.
All above models are designed for use with the Apollo (Discovery, Explorer, XP95 and Series 90) and Hochiki
(ESP) fire detection devices.
1.3.2 5000V Series
The 5100V is a Single Loop, Analogue Addressable Fire Alarm Control Panel.
The 5200V is a Two Loop, Analogue Addressable Fire Alarm Control Panel.
The 5400V is a Multiple Loop, Analogue Addressable Fire Alarm Control Panel with provision for up to four
loops.
All above models are designed for use with the Advanced (AV) fire detection devices.
1.3.3 5000N Series
The 5100N is a Single Loop, Analogue Addressable Fire Alarm Control Panel.
The 5200N is a Two Loop, Analogue Addressable Fire Alarm Control Panel.
The 5400N is a Multiple Loop, Analogue Addressable Fire Alarm Control Panel with provision for up to four
loops.
All above models are designed for use with the Nittan Evolution fire detection devices.
