3.9.7.2 Local Hardware
The Local Hardware Option provides a diagnostic readout of the operational condition and readings for the
internal panel electronic circuits of this panel. When the option is selected, the display shows a list of the
circuits. For example:
[Panel Circuits]
DESCRIPTION VALUE STATE
Sounder A 5.6V Normal
Sounder B 5.6V Normal
Sounder A Load 0mA Normal
Sounder B Load 0mA Normal
The following table lists the internal panel circuits and indicates the values that can be displayed.
Description
Value Range
Normal
Possible States
Sounder A
0V – 14V
5.5V
Normal
Open Circuit, Short Circuit
Sounder B
4
Sounder A Load
0mA – 1000mA
5
Normal
Too High
Sounder B Load
4
Battery
0V – 30V
27.6V
Normal
Too High, Too Low
Charger
0V – 30V
28.0V
Normal
Too High, Too Low
Charger Current
0mA – 2000mA
5
Normal
Charger Temp (C)
0C – 50C
5
Normal
Earth Volts
0V – 30V
2.5V /
14.5V
6
Normal
Too High, Too Low
System Volts
19V – 30V
28.0V
Normal
Aux Load
0mA – 500mA
5
Normal
Too High
1
st
Loop Load
7
0mA – 500mA
5
Normal
Open Circuit, Too High, Short Circuit
1
st
Loop V.Out
7
24V – 32V
5
Normal
1
st
Loop V.In
7
24V – 32V
5
Normal
Panel Switch Inputs
1-9
L/H
L
Normal
Programmable inputs
Normal
L/H
L
Normal
Relay 1
–
–
Normal
Relay 2
–
–
Normal
Relay 3
8
–
–
Normal
Relay 4
8
–
–
Normal
Main Supply
–
–
Normal
Pager
–
–
Normal
Press the  buttons to scroll through the panel internal circuits. Press the ‘Esc’ button to return to the main
view menu.
NOTE: Additional panel circuits may be shown depending on the system configuration and installed options.
4
The 5400 also displays Sounders C and D.
5
Depends on the panel configuration, installation and current operating condition (i.e. fire alarm).
6
Depends on configuration of the panel.
7
Loop Load, V.Out and V.In displayed for each loop driver (2 on 5200, 4 on 5400).
8
Requires the installation of the 2-Way Relay card option.
