Advanced Poly-Packaging T-1000 - Page 84

83
PLC Exp1
X
25
Light Curtain signal
on
PLC Exp1
X
26
DF-20 Eye
off
PLC Exp1
X
27
Barcode 'Quality Error'
off
PLC Exp1
X
28
US50: Tray Home sensor
on
PLC Exp1
X
29
US50: Tray Out sensor
off
PLC Exp1
X
2A
MV10 Temperature alarm
off
PLC Exp1
X
2B
MV10 Pressure alarm
off
PLC Exp1
X
2C
Barcode 'GOOD READ'
off
PLC Exp1
X
2D
BO-30 Bag Open sensor
off
PLC Exp1
X
2E
BO30: Home sensor
on
PLC Exp1
X
2F
Barcode 'NO READ'
off
PLC Exp1
X
30
Not Used - Not Available
PLC Exp1
X
31
Not Used - Not Available
PLC Exp1
X
32
Not Used - Not Available
PLC Exp1
X
33
Not Used - Not Available
PLC Exp1
X
34
Not Used - Not Available
PLC Exp1
X
35
Not Used - Not Available
PLC Exp1
X
36
Not Used - Not Available
PLC Exp1
X
37
Not Used - Not Available
PLC Exp1
X
38
Not Used - Not Available
PLC Exp1
X
39
Not Used - Not Available
PLC Exp1
X
3A
Not Used - Not Available
PLC Exp1
X
3B
Not Used - Not Available
PLC Exp1
X
3C
Not Used - Not Available
PLC Exp1
X
3D
Not Used - Not Available
PLC Exp1
X
3E
Not Used - Not Available
PLC Exp1
X
3F
Not Used - Not Available
PLC Exp2
WX
4
Analog Input (Thermocouple J) TC1
PLC Exp2
WX
5
Not Used - Available
Outputs
Main PLC
Y
0
Stepper PulseTrain CW
Main PLC
Y
1
Stepper PulseTrain CCW
Main PLC
Y
2
H/V trigger
Main PLC
Y
3
Heater control
Main PLC
Y
4
Air Blower solenoid
Main PLC
Y
5
Air Pulse solenoid
Main PLC
Y
6
Heater Bar solenoid
Main PLC
Y
7
Seal Bar Out solenoid
Main PLC
Y
8
Seal Bar In solenoid
Main PLC
Y
9
Blow Off solenoid
