Advanced Poly-Packaging T-1000 - Page 85

84
Main PLC
Y
A
TIZ NBO Print request
Main PLC
Y
B
Station #5 solenoid
Main PLC
Y
C
H/V Armed (for 220V)
Main PLC
Y
D
LC-10 Power relay
Main PLC
Y
E
TIZ INL Print request
Main PLC
Y
F
Auxiliary Out
Main PLC
Y
10
Not Used - Not Available
Main PLC
Y
11
Not Used - Not Available
Main PLC
Y
12
Not Used - Not Available
Main PLC
Y
13
Not Used - Not Available
Main PLC
Y
14
Not Used - Not Available
Main PLC
Y
15
Not Used - Not Available
Main PLC
Y
16
Not Used - Not Available
Main PLC
Y
17
Not Used - Not Available
Main PLC
Y
18
Not Used - Not Available
Main PLC
Y
19
Not Used - Not Available
Main PLC
Y
1A
Not Used - Not Available
Main PLC
Y
1B
Not Used - Not Available
Main PLC
Y
1C
Not Used - Not Available
Main PLC
Y
1D
Not Used - Not Available
Main PLC
Y
1E
Not Used - Not Available
Main PLC
Y
1F
Not Used - Not Available
PLC Exp1
Y
20
UF5k Run
PLC Exp1
Y
21
Not Used - Available
PLC Exp1
Y
22
Barcode Read trigger
PLC Exp1
Y
23
Not Used - Available
PLC Exp1
Y
24
US-5000 Flip solenoid
PLC Exp1
Y
25
Stack Light Red
PLC Exp1
Y
26
Stack Light Yellow
PLC Exp1
Y
27
Stack Light Green
PLC Exp1
Y
28
Station #6 solenoid
PLC Exp1
Y
29
Station #7 solenoid
PLC Exp1
Y
2A
Station #8 solenoid
PLC Exp1
Y
2B
Station #9 solenoid
PLC Exp1
Y
2C
Station #10 solenoid
PLC Exp1
Y
2D
Stand Adjust: Bagger UP
PLC Exp1
Y
2E
Stand Adjust: Bagger DOWN
PLC Exp1
Y
2F
UF5k: Drive Alarm reset
PLC Exp1
Y
30
Not Used - Not Available
PLC Exp1
Y
31
Not Used - Not Available
PLC Exp1
Y
32
Not Used - Not Available
PLC Exp1
Y
33
Not Used - Not Available
