Triggering Signals to Equipment within the System.
22
The general fire alarm outputs can be used / configured to transmit triggering signals
to extinguishing system equipment such as pilot cylinders, warning devices, etc.
If required, the outputs can be non-silencing. These outputs can be individually
disabled (sounder-1 / sounder-2).
3.3.2.2 Pulse Pattern Configuration
Activation of Alarm Devices with Different Signals.
Signals during the pre-discharge warning period should be intermittent and signals
during the activated / released condition should be continuous.
In addition to turning the sounders ON, the sounders can be pulsed as an alert tone. Three separate pulse
patterns can be configured.
[Pulse Pattern]
PULSE-1 ON 1s.
PULSE-1 OFF 4s
PULSE-2 ON 1s
PULSE-2 OFF 1s
HOLD PULSE ON 1s
Use the buttons to highlight the required pulse period
and then press the button to select it.
A menu of parameters is presented for the selected
sounder.
[Number Entry]
Value: 1
Enter New Value:-
0
Maximum: 7
The current on/off period is shown.
Enter a new on/off period as required.
Specifies the Sounder ON period during an ALERT
condition.
Specifies the Sounder OFF period during an ALERT
condition.
Specifies the Sounder ON period during an ALERT
condition.
Specifies the Sounder OFF period during an ALERT
condition.
Specifies the Sounder ON period during the HOLD
condition.
Specifies the Sounder OFF period during the HOLD
condition.
From Software Version 2.02 :
A second ALERT pulse type (PULSE-1) is provided. The original ALERT pulse type is now renamed as PULSE-
2 and this is the default pulse pattern for the COUNTDOWN condition.
Do not use SNDR3 for these functions.
ON normally takes precedence over PULSE patterns. Exceptions: during the pre-discharge countdown or during a hold condition.
The mark to space ratio of the HOLD PULSE signal should be configured to create a different and unique pattern to the standard Alert
PULSE-1 or PULSE-2 patterns.
