3.3.5 Outputs
The display presents a list of the programmable outputs along with their current settings.
[Prog. Outputs]
RELAY 1 .
> NOT IN USE .
RELAY 2
* GENERAL FAULT
AUX RELAY 1
Use the  buttons to highlight the required output and then
press the  button to select / change it.
The table below details each available output and the
programmable settings available. The output can also be
configured as an INVERTED output (indicated by an *
character). In this mode, it is normally turned on and will turn off
when the applicable cause & effect occurs.
[Output Settings]
MODE: .
NOT IN USE .
INVERTED: NO
Use the  buttons to highlight the required option and then
press the  button to select / change it.
The default settings are as follows:
RELAY 1: STAGE-1 [INVERTED = NO]
RELAY 2: RELEASED [INVERTED = NO]
AUX RELAY 1 – 8: NOT IN USE [INVERTED = NO]
SWITCHED AUX: RESET [INVERTED = YES]
Outputs
Setting Options
Comments
RELAY 1
NOT IN USE
The Output is not used and will not activate.
RELAY 2
FOLLOW SOUNDER 1
The output is activated when Sounder 1 is activated.
AUX RELAY 1
FOLLOW SOUNDER 2
The output is activated when Sounder 2 is activated.
AUX RELAY 2
FOLLOW SOUNDER 3
The output is activated when Sounder 3 is activated.
AUX RELAY 3
GENERAL FIRE
The output is activated if any fire condition event occurs.
AUX RELAY 4
GENERAL FAULT
The output is activated if any fault condition event occurs.
AUX RELAY 5
STAGE-1
The output is activated when a first stage alarm is recognized.
30
AUX RELAY 6
STAGE-2
The output is activated when a second stage release is recognized and the
actuator output is due to be operated.
AUX RELAY 7
RELEASED
The output is activated when the release of extinguishant has been completed.
AUX RELAY 8
ON HOLD
The output is activated when the release of extinguishant has been held.
SWITCHED AUX
ABORTED
The output is activated when the release is aborted. It remains in this state until
the panel is reset.
MANUAL MODE
The output is activated when the manual only mode is selected. (In the off
position the output indicates auto+manual).
VALVE CLOSED
The output is activated when the valve monitor is active.
RESET
The output is activated for approximately 10-15 seconds when the panel is
reset.
ZONE1 or STAGE-2
The output is activated when a second stage release is recognized OR the fire
alarm is from Zone 1.
ZONE2 or STAGE-2
The output is activated when a second stage release is recognized OR the fire
alarm is from Zone 2.
ZONE3 or STAGE-2
The output is activated when a second stage release is recognized OR the fire
alarm is from Zone 3.
EXTRACT
The output is activated when the extract phase is in process.
TEST MODE
The output is activated when any of the zones are in a test state.
SUPERVISORY
The output is activated during a ‘Pressure Low’ or ‘Valve Stuck’ condition.
DISABLEMENT
The output is activated whenever any disablement condition is present except
for the disablement of programmable releays.
WARNING
The output is activated whenever a “Valve Closed”, “Aborted”, “Hold” or
“Manual Only” condition is present.
FIRE + MAN. TRIG
The output is activated whenever a Fire condition exists or a manual trigger
has been used to initiate the release of gas. Remains active until a successful
Gas Reset (for Manual trigger condition) or while ever the Fire state persists.
30
NOTE: Stage-1 will also be activated as soon as an immediate Stage-2 condition (i.e. manual release or single zone fire alarm activation)
occurs.
