Advanced ExGo Ex-3001 User Manual

www.advancedco.com
25
3.1.5 Numeric data entry
Numbers are entered by moving to the required field, and then typing in the required number, followed by the 
button. The display returns to the previous menu.
If the number is entered incorrectly, press the  button to clear the entry and then re-enter the required
number. Alternatively, press the ‘Esc’ button to cancel the number entry and return to the previous menu.
3.2 Recommended Programming Procedure
It is recommended that the configurable options be programmed in the following sequence:
 Configure General Options and Passwords
 Configure the Extinguishing Output Type and Cause & Effect Rule
 Configure the Detection Zone Input Circuits
 Configure the Alarm Outputs and Cause & Effect Rule
 Configure any other Input / Output Circuits
3.3 Level 3 Menu Functions
The following table gives a list of the Level 3 Menu Functions and a brief description for each function.
Menu Option
Sub Menu
Comments / Description
3
DETECTION
ZONE 1
ZONE 2
ZONE 3
Configuration of the Detection Zone Input Circuits
4
ALARM OUTPUTS
SOUNDER 1
SOUNDER 2
SOUNDER 3
PULSE PATTERN
Configuration of the Alarm Sounder Output Circuits and
pulsing operation
2
EXTINGUISHING
OUTPUT SET-UP
Configuration of the Actuator Output Circuit
CAUSE & EFFECT
Configuration of the release cause and effects rule
EXTRACT SET-UP
Configuration of the Extract Output
5
INPUTS
Configuration of the Programmable Input Circuits
5
OUTPUTS
Configuration of the Programmable Output (Relay) Circuits
1
PASSWORDS
Configuration of the Engineer and User Passwords
1
GENERAL
Configuration of General parameters
5
STATUS INDICATORS
Configuration of any Remote Status Indicator Panels
ENABLE P.C. LINK
Permits the connection of a PC for upload of a logo or
download of the configuration and log files.
EXIT
Leave the Commission Menu
To enter the Commissioning / Programming Menu, select the COMMISSION option in the Level 2 Menu and
press the  button. The display prompts for the Level 3 password.
To exit from the Commissioning / Programming Menu, select the EXIT option and press the  button. The
display prompts for the Level 3 password.
