5.2 Appendix 2 – Compatible Devices
5.2.1 Detectors
Manufacturer
Part Number
Description
№ /
Zone
№ / Zone
(Schottky
bases)
32
Apollo
55000-215
Series-65 Ion smoke
32
26
55000-216
Series-65 Ion smoke
32
26
55000-217
Series-65 Ion smoke
32
26
55000-218
Series-65 Ion smoke (Integrating)
32
26
55000-219
Series-65 Ion smoke (Integrating)
32
26
55000-220
Series-65 Ion smoke (Integrating)
32
26
55000-315
Series-65 Photo-smoke
32
26
55000-316
Series-65 Photo-smoke
32
26
55000-317
Series-65 Photo-smoke
32
26
55000-120
Series-65 Heat A1R
30
26
55000-121
Series-65 Heat A1R
30
26
55000-122
Series-65 Heat A1R
32
26
55000-125
Series-65 Heat BR
30
26
55000-126
Series-65 Heat BR
30
26
55000-127
Series-65 Heat BR
32
26
55000-130
Series-65 Heat CR
30
26
55000-131
Series-65 Heat CR
30
26
55000-132
Series-65 Heat CR
32
26
55000-135
Series-65 Heat CS
30
26
55000-136
Series-65 Heat CS
30
26
55000-137
Series-65 Heat CS
32
26
Apollo
ORB-OP-12001-APO
ORBIS Photo-smoke
16
16
ORB-OH-13001-APO
ORBIS Multi-sensor
16
16
ORB-HT-11001-APO
ORBIS A1R Heat
16
16
ORB-HT-11002-APO
ORBIS A2S Heat
16
16
ORB-HT-11003-APO
ORBIS BR Heat
16
16
ORB-HT-11004-APO
ORBIS BS Heat
16
16
ORB-HT-11005-APO
ORBIS CR Heat
16
16
ORB-HT-11006-APO
ORBIS CS Heat
16
16
ARGUS
Aurora-DN / S100 (using
330R base)
Photo smoke
18
16
Aurora-TN / S400
(using 330R base)
Heat (RoR)
22
16
Aurora-DTN / S200
(using 330R base)
Multi
19
16
Argo (using 330R base)
Heat (58deg Fixed)
24
16
S300 (using 330R base)
Heat (75deg Fixed)
24
16
Hochiki
SLR-E3
CDX Photo-smoke
32
24
DCD-AE3
CDX Heat
32
24
32
The number of devices that can be fitted to a zone when using schottky diode bases. The figure stated ensures that all detector fires/
faults are registered under various worst case scenarios e.g. Fire detection with devices removed from bases:- all but the last device
removed from it’s base; 32 Ohms cable impedance; no E.O.L device fitted (open circuit).
Also note that calculations assume an Active end of line device exhibiting a ‘fault current’ of no more than 40uA.
