Chapter 6
Planning Your Application Program
(cr) is the terminating character, carriage return (0Dh)
Example command: $01S1C2314(cr)
response: !01(cr) The command tells channel 2 of
the analog output module in slot 1 of the ADAM-
5000/TCP system at address 01h to increase its
output value by 20 (14h) counts which is
approximately 30
µA.
The analog output module
confirms the increase.
Note: In order to perform a Trim Calibration, either a mA meter or a
resistor and voltmeter should be connected to the
module’s
output prior to calibration.
6-138 ADAM-5000/TCP User’s Manual
