Chapter 1
Understanding Your System
1-3-9 Basic Function Block Diagram
Figure 1-3: Function block diagram
1-4 LED Status of ADAM-5000/TCP Series main unit
There are eight LEDs on the ADAM-5000/TCP Series front panel. The
LEDs indicate ADAM-5000/TCP’s system status, as explained below:
Figure 1-4: ADAM-5000/TCP LED Indicators
1-8 ADAM-5000/TCP User’s Manual
