Chapter 3
Hardware Installation Guide
3-4-3 System Network Connections
Ethnet Network
The ADAM-5000/TCP Series has an Ethernet communication port
allowed you to program, configure, monitor, and integrate into the
SCADA system. The figure 3-8 is a guideline to complete the system
network connection.
Figure 3-8: System network connection
3-8 ADAM-5000/TCP User’s Manual
