Chapter 2 Selecting Your Hardware Components
2-2 Selecting Power Supply
ADAM-5000/TCP S e r i e s system works under unregulated power
source be- tween +10 and +30 VDC. When you arrange different I/O
modules on ADAM-5000/TCP’s back plant, it may require comparable
power supply. Use the following steps as guidelines for selecting a
power supply for your ADAM-5000/TCP system.
• Refer to table 2.3 to check the power consumption of ADAM-5000/
TCP Series main unit and each I/O module.
Main Units Description Power Consumption
ADAM-5000/485 Distributed Data Acquisition and Control System based on RS-485 1.0 W
ADAM-5000E Distributed Data Acquisition and Control System based on RS-485 4.0 W
ADAM-5000/TCP Distributed Data Acquisition and Control System based on Ethernet 5.0 W
ADAM-5510 PC-Based Programmable Controller (With Battery Backup) 1.0 W
ADAM-5510M Enhanced PC-Based Programmable Controller (With Battery Backup) 1.2 W
ADAM-5511 PC-Based Programmable Controller with Modbus 1.0 W
ADAM-5510E 8-clot PC-Based Programmable Controller 1.2W
ADAM-5510/TCP Ethernet-enabled PC-Based Programmable Controller 2.0W
ADAM-5510E/TCP 8-clot Ethernet-enabled PC-Based Programmable Controller 2.0W
I/O Modules Description Power Consumption
ADAM-5013 3-Channel RTD Input Module 1.1 W
ADAM-5017 8-Channel Analog Input Module (mV, mA or High Voltage) 1.25 W
ADAM-5017H 8-Channel High speed Analog Input Module (mV, mA or High Voltage) 2.2 W
ADAM-5017UH 8-Channel Ultra High speed Analog Input Module (mV, mA or High Voltage) 2.2 W
ADAM-5018 7-Channel Thermocouple Input Module (mV, V, mA, Thermocopule) 0.63 W
ADAM-5024 4-Channel Analog Output Module (V, mA) 2.9 W
ADAM-5050 16-Channel Universal DIO 1.2 W
ADAM-5051 16-Channel Digital Input Module 0.53 W
ADAM-5051D 16-Channel Digital Input w/LED Module 0.84 W
ADAM-5056S 16-Channel Isolated Digital Input w/LED Module 0.8 W
ADAM-5056SO 16-Channel Digital Input w/LED Module 0.84 W
ADAM-5052 8-Channel Isolated DI 0.27W
ADAM-5055S 16-Channel Isolated DIO w/LED Module 0.68 W
ADAM-5056 16-Channel Digital Output Module 0.53 W
ADAM-5056D 16-Channel Digital Output w/LED Module 0.84 W
ADAM-5056S 16-Channel Isolated Digital Output w/LED Module 0.6 W
ADAM-5060 6-Channel Relay Output Module ( 2 of Form A, 4 of Form C) 1.8 W
ADAM-5068 8-Channel Relay Output Module ( 8 of Form A) 1.8 W
ADAM-5080 4-Channel Counter/ Frequency Input Module 1.5 W
ADAM-5090 4-Port RS232 Module 0.6 W
Table 2-3: Power Consumption of ADAM-5000 series
2-6
ADAM-5000/TCP User’s Manual
