Appendix A
Design Worksheets
Step 3: Mapping the I/O data base into ADAM-5000/TCP system.
1) In column A, note the ADAM-5000/TCP IP addresses mapped
for individual function areas.
2) In column B, list the I/O module’s product number.
3) In column C, enter the maximum number of I/O points available per
module.
4) In column D, total the number of the I/O point you need.
5) In column E, calculate the total number of these modules that you will
need for these ADAM-5000/TCP systems.
6) In column F, enter the number of spare modules that you may need for
future expansion in these ADAM-5000/TCP systems.
7) In column G, enter the total number (Required + Spare) of these mod-
ules that you need for these ADAM-5000/TCP systems.
A-4 ADAM-5000/TCP User’s Manual
