Appendix B
Data Formats and I/O Ranges
B.4.1 Analog Input Ranges - ADAM-5017UH
Range
Code
Input
Range
Data Formats
+Full
Scale
Zero
-Full
Scale
Displayed
Resolution
08h ±10 V Engineering +10.000 +00.000 -10.000 1 mV
Two's Comp 0FFF 0 7FFF 1
48h 0 ~ 10 V Engineering +10.000 +00.000 - 1 mV
Two's Comp 0FFF 0 Don't care 1
46h 0~20mA Engineering +20.000 +00.000 -
1μV
Two's Comp 0FFF 0 Don't care 1
07h 4~20mA Engineering +20.000 +00.000 -
1μV
Two's Comp 0FFF 0 Don't care 1
Note: The full scale values in this table are theoretical values for your
reference; actual values will vary.
ADAM-5000/TCP User’s Manual B-8
