Advantech AIMB-240 Series User Manual

AIMB-240 Series
14 AIMB-240 Series User’s Manual
Display
Model
AIMB-240F-00A1E
Chipset
Intel
®
852GME GMCH integrated Extreme Graphics 2 controller
Display Memory
Intel
®
DVMT 2.1 supports up to 64 MB video memory
Resolution
CRT mode: 1600 x 1200 @ 32 bpp (85 Hz)
LCD/Simultaneous mode: 1600 x 1200 @ 32 bpp (85 Hz)
Dual Display
CRT + LVDS, or DVI/TV-out + LVDS or CRT + DVI
LVDS
Single-channel 18-bit/ Dual-channel 36-bit LVDS
DVI
Chrontel CH7009A DVI transmitter up to 135M pixels/second
TV-Out
Chrontel CH7009A TV encoder supports both NTSC/PAL
Supports both S-Video and composite video
Audio
Chipset Intel® ICH4
AC97 Codec
Realtek
TM
ALC655 supports 5.1CH AC97 Audio
Audio Interface Mic in, Line in, CD Audio in, Line out
Ethernet
LAN1
Realtek RTL8110C 10/100 Mbos
LAN2
Realtek RTL8110C 10/100 Mbos
Ethernet Interface
100 Base-Tx Fast Ethernet compatible: Realtek
TM
RTL8110C
