AIMB-240 Series
30 AIMB-240 Series User’s Manual
2.2.2 Main Memory
AIMB-240 provides one 184-pin DIMM socket to support DDR SDRAM. The total maximum
memory size is 1GB.
Make sure to unplug the power supply before adding or removing DIMMs or
other system components. Failure to do so may cause severe damage to
both the board and the components.
DIMM1
