AIMB-240 Series
26 AIMB-240 Series User’s Manual
2.1 Product Overview
DIMM
LVDS
JTMDS1
ATXPWR
ATX12V
KBMS
IrDA
COM1_1
COM2
COM2 RS
COM 3/4/5/6
CPU Fan
RJ-45 & 2 USB
VGA
Parallel Port
System Fan
Floppy
Primary
IDE
Secondary
IDE
LCD
Inverter
CD-ROM Audio-In
Digital In/Out
Front Panel
TV Out
LVLCPW
PCI
