User’s Manual
AIMB-240 Series User’s Manual
13
1.5 System Specifications
System
Model
AIMB-240F-00A1E
CPU
Supports Intel
®
µFC-PGA 478 Pentium
®
4 / Celeron
TM
up to 2.8 GHz with 0.13µ
process technology
FSB
400/533 MHz
BIOS
Award 512 KB Flash BIOS
System Chipset
Intel
®
852GME GMCH/ICH4
I/O Chip
Winbond W83627HF-AW
System Memory
One 184-pin DIMM socket supports up to 1 GB DDR 266/333 SDRAM
SSD
One Compact Flash Type I/II socket
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats.
Expansion
One PCI slot (PCI Rev. 2.2 compliant)
I/O
MIO
2 x EIDE (Ultra DMA 100), 1 x FDD , 1 x LPT, 5 x RS-232, 1x RS-232/422/485, 1x
K/B, 1 x Mouse
IrDA
115k bps, IrDA 1.0 compliant
USB
6 x USB 2.0 ports
DIO
16-bit General Purpose I/O for DI and DO
