Advantech AIMB-781 - VGA Connector and DVI-D Connector (VGA1+DVI1)

17 AIMB-781 User Manual
Chapter 2 Connecting Peripherals
2.5 VGA Connector and DVI-D Connector
(VGA1+DVI1)
The AIMB-781 includes both VGA and DVI-D interface that can drive conventional
CRT and LCD displays. Pin assignments of VGA1 and DVI1 are detailed in Appendix
B.
DVI1 + VGA1
5
15
1
11
10 6
