AIMB-781 User Manual 46
Case Open Warning
Enable/Disable the Chassis Intrusion monitoring function. When enabled and the
case is opened, the speaker beeps.
CPU Warning Temperature
Use this to set the CPU warning temperature threshold. When the system reaches
the warning temperature, the speaker will beep.
ACPI Shutdown Temperature
Use this to set the ACPI shutdown temperature threshold. When the system reaches
the shutdown temperature, it will be automatically shut down by ACPI OS to protect
the system from overheat damage.
CPUFAN Mode Setting
“Enable or Disable” CPUFAN Mode to SMART FAN setting
3.3.10 F81216 Super IO Configuration
Figure 3.17 F81216 Super IO Configuration
AIMB-781QG2 version supports 2nd super IO for Com 3~6, so this page of bios
menu is to set respective serial port configuration.
