25 AIMB-781 User Manual
Chapter 2 Connecting Peripherals
2.15 Front Panel LAN Indicator Connector
(LAN_LED1)
Table 2.2: Front Panel LAN Indicator Connector
LAN Mode Indicator
G-LAN Link ON Green ON
G-LAN Active Green Flash
G-LAN Link Off Green OFF
LANLED1
