ARK-2150 User Manual 4
 Speed: 1000 Mbps
 Interface: 4 x RJ45
 Standard: Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3y,
IEEE 802.ab.
1.3 Chipset
1.3.1 Functional Specification
1.3.1.1 Processor
1.3.1.2 Chipset
Processor
Intel Celeron 1047UE 1.4GHz/Core i3 3217UE 1.6GHz / Core i7 1.7 GHz
with 3MB/4MB L2 cache
Manufacturing Technology:22nm
Memory
Supports DDR3 1600 MHz or DDRL3 1333MHz up to 8 GB
1 x 204-pin SODIMM socket type
Internal Graph-
ics Features
 DirectX 11 and OpenGL 3.0
 Display Part 1.1, HDMI 1.3a
 Supports HDCP 1.3
 Intel Display Power saving technology 6.0
 SGXS45 Power VR Core 400/640 MHz
Video Accelera-
tor
 HW accelerated Media Decode: AVC/H.264, VC-1, MPEG-2
 HW accelerated Media Encode: AVC/H.264, MPEG-2
SATA Interface
Intel QM77 chip supports:
 Supports several optional sections of Serial ATA III
 Supports SATA transfers to 600 Mbytes/sec.
 Integrated AHCI controller
 Supports mSATA socket
USB Interface
Intel QM77 chip supports:
 xHCI Host Controller, supporting SuperSpeed USB 3.0 ports
 Two EHCI Host Controllers, supporting HighSpeed USB 2.0 ports
 Supports wake-up from sleeping states S1–S4
 Supports legacy Keyboard/Mouse software
 Maximum 500mA for each USB port
Power
Management
Intel QM77 chip supports:
 Supports ACPI 4.0a
 ACPI-defined power states (processor driven C states)
 ACPI Power Management Timer
 SMI# generation
BIOS
Intel QM77 chip supports:
 AMI 64-Mbit EFI Flash BIOS via SPI
