ARK-2150 User Manual 6
1.3.2 iManager
DIO
ITE 8518E or PCA9554 supports:
ARK-2150L:
– 9 I/O pins with one ground pin
– 5V tolerance I/Os.
*ARK-2150L: 9 pins DSUB 9 connector
ARK-2150F:
Isolated Digital Input
– Number of Channel: 4
– Optical Isolation: 2,500 VDC
– Opto-isolator response time: 25μs
– Input Voltage: VIH (max.) 30 VDC
VIH (min.) 5 VDC
VIL (max.) 2 VDC
– Input Current: 5 VDC 1.4 mA (typical)
12 VDC 3.9 mA (typical)
24 VDC 8.2 mA (typical)
30 VDC 10.3 mA (typical)
Isolated Digital Output
– Number of Channel: 4
– Optical Isolation: 2,500 VDC
– Output Voltage: Open collector 5 to 40 VDC
– Sink Current: 200 mA max./channel
*ARK-2150F: 10 pins phoenix connector
DIO Connectors:
 ARK-2150L: 9 pins DSUB 9 connector
 ARK-2150F: 10 pins phoenix connector
Battery backup  BATTERY 3V/210 mAh with WIRE x 1
iManager
Sequence control Supported
DIO 8-bit programmable DIO
Watchdog timer Multi Level WDT (set by Advantech iManager)
Programmable 1-255 sec / min
Hardware monitor CPU Temperature / input Current / input Voltage
Power saving Deep sleep S5 mode / Smart Fan / Back light control
System information Running HR / Boot record
