Advantech MIC-770 User Manual

3 MIC-770 User Manual
Chapter 1 General Introduction
1.2.3 Ethernet
 Chipset:
– Q370 LAN1: Intel® I219LM, LAN2: Intel® i210IT
– H310 LAN1: Intel® I219V, LAN2: Intel® i210IT
 Speed: 10/100/1000 Mbps
 Interface: 2 x RJ45
 Standard: Compliant with IEEE 802.3, IEEE802.3u, IEEE 802.ab.
1.3 Chipset
1.3.1 Functional specification
1.3.1.1 Processor
1.3.1.2 Chipset
Processor Intel® 8th Gen Core™ i CPU socket (LGA1151)
PCH  Intel® Q370/H310 chipset
Memory
 Supports DDR4 2133/2400/2666MHz (without ECC)
 SODIMM Socket:
– 260-pin SODIMM socket*2 (up to 16 GB per socket)
Chipset
integrated Intel
HD Graphic
 Intel® HD Graphics 630/610
 Supports DirectX 12
 Supports OpenGL 4.4
 Supports Intel® Quick Sync Video
 IO interface
– VGA: Supports resolutions up to 2048 x 1152 @ 60 Hz
(VGA connector: On-board D-SUB 15P)
– HDMI: Supports resolution up to 3840×2160 @30Hz
(HDMI Connector: On-board HDMI)
SATA Interface
 3 x SATA3.0 (Q SKU), 1 x SATA3.0 (H SKU)
 Legacy IED (Including IRQ)/Native AHCI appearance to OS
 Partial/slumber power management modes with wake
 Capable of 6Gbit/s transfer rate
USB Interface
 Q370: 2 x USB3.1, 6 x USB3.0 and 1 x internal USB 2.0
 H310: 4 x USB 3.0 and 4 x USB 2.0
 Supports high-speed, full-speed, and low-speed capable
 Supports legacy keyboard/mouse software
Power
Management
 Supports ACPI 5.0
 ACPI Power Management Logic supported
 Power Connector: plug-in block 4Px1
BIOS  AMI 256Mb Flash BIOS via SPI
