Advantech MIC-770 User Manual

MIC-770 User Manual vi
Packing List
Before installation, please ensure the following items have been shipped:
Ordering Information
Optional i-Module
 MIC-770 bare-bone system x1
 MIC-770 Startup manual x1 P/N: 2041077000
 4-pin Phoenix connector P/N: 1652003234
 Mounting bracket x2 P/N: 1960070543T001
 SATA cable x1 P/N: 1700013095
 SATA Power cable x1 P/N:1700024372-01
 Thermal pad for memory P/N: 1990019498N000
 Thermal grease for CPU P/N: 2170000093-01
Module
Number
PCH VGA HDMI
2.5' HDD/
SSD
USB3.1/
3.0/2.0
GbE COM
PCIE/PCI
Exp
Power
MIC-770Q-00A1 Q370 1 1 1 2/6/0 2
2, up to 6
via cable
i-module
(Optional)
DC9~36V
MIC-770H-00A1 H310 1 1 1 0/4/4 2
2, up to 6
via cable
i-module
(Optional)
DC9~36V
Module Number Description
4-slot expansion module
MIC-75M13-00A1E 1 x PCIe x16+3xPCI slot i-module
MIC-75M40-00A1E 1 x PCIe x8+3xPCIe x4 slot i-module
2-slot expansion module
MIC-75M20-00B1 1 x PCIe x16+1xPCIe x4 slot i-module
MIC-75M20-01A1E 2 x PCIe x8 slot i-module
MIC-75M11-00A1E 1 x PCIe x16+1xPCI slot i-module
MIC-75G20-00A1
1 x PCIe x16 (Doible Deck)+1xPCIe x4+2x2.5" hot-swap HDD/SSD
GPU slot i-module
2-slot expansion and storage module
MIC-75S20-00A1E 1 x PCIe x16+ 1 x PCIe x4 slot+ 2x2.5” swappable HDD/SSD
1-slot expansion module
MIC-75M10-00A1 1 x PCIe x16 slot
