Appendix D System Assignments
97
D.2
DMA channel assignments
Table D-2: DMA channel assignments
Channel
Function
0
Available
1
Available
2
Floppy disk (8-bit transfer)
3
Available
4
Cascade for DMA controller 1
5
Available
6
Available
7
Available
* Audio DMA select 0, 1 or 3
