Appendix C Pin Assignments
87
C.14
COM2 RS-232 connector (CN15)
Table C-13: COM2 RS-232 connector (CN15)
Pin
RS-232 port
Pin
RS-232 port
1
DCD
6
CTS
2
DSR
7
DTR
3
RxD
8
RI
4
RTS
9
GND
5
TxD
10
N/C
