22 PCA-6751 Series User's Manual
2.12 VGA display connector (CN11)
The PCA-6751 Series provides a VGA controller for a high resolution
VGA interface. The PCA-6751Series' CN7 is a DB-15 connector for
VGA monitor input. Pin assignments for the CRT display are detailed
in Appendix C.
2.13 PC/104 connectors (CN12)
The PCA-6751 Series is equipped with a 16-bit ISA signal PC/104
connector for future expansion. See Appendix B for details.
2.14 Ethernet connector (CN13)
(PCA-6751 only)
The PCA-6751 is equipped with a high performance 32-bit PCI-bus
Fast Ethernet interface which is fully compliant with IEEE 802.3u
100/10Base-T specifications. It is supported by all major network
operating systems.
The medium type can be configured via the Intel82558.EXE program
included on the utility disk. (See Chapter 5 for detailed information.)
2.14.1 RJ-45A connector (CN13)
100/10Base-T connects to the PCA-6751 via an adapter cable to the
RJ-45 standard jack.
2.14.2 Network boot
The network boot feature is built into the BIOS. It can be enabled or
disabled in the chipset setup of the CMOS configuration. Refer to
"BIOS Setting" in Chapter 4 for more information.
