Pin Assignments
This appendix contains information of a
detailed or specialized nature. It includes:
• FDD connector
• Parallel port connector
• Keyboard lock connector
• USB connector
• 24-bit LCD display connector
• 36-bit LCD display connector
• LCD inverter connector
• IR connector
• External speaker connector
• VGA connector
• PC/104 connector
• Ethernet connector
• COM2 RS-422/485 connector
• COM2 RS-232 connector
• COM1 RS-422/485 connector
• External keyboard connector
• ATX power connector
• AT power connector
• Keyboard and PS/2 mouse connector
• CompactFlash™ card connector
• HDD LED connector
• System reset switch connector
• ATX power button
• Enhanced IDE connector
APPENDIX
C
