Chapter 1 Hardware Configuration 3
1.2 Specifications
Standard SBC functions
• CPU: Intel Pentium
®
MMX CPU 166/266 MHz
• BIOS: AWARD 2 Mbit Flash BIOS, supports Plug & Play, APM
1.2, Ethernet boot ROM, boot from CD-ROM, LS-120, and ZIP
drive
• Chipset: Intel
®
430 TX
• L2 cache: 512 KB PB SRAM
• System memory: Two 144-pin SODIMM RAM sockets support
SDRAM memory module from 8 MB to 256 MB
• PCI IDE interface: One Enhanced IDE interface, supports 2 IDE
devices PIO mode 3, 4 with bus mastering up to 14 MB/sec Ultra
DMA mode up to 33 MB/sec
• Floppy disk drive interface: Supports up to two floppy disk drives:
3½" (720 KB or 1.44 MB) and/or 5¼" (360 KB or 1.2 MB)
• Parallel port: One parallel port , supports SPP/EPP/ECP
• IR port: Supports up to 115 Kbps transmission rate
• Serial ports: one RS-232, one RS-232/422/485
• Watchdog timer: Can generate a system reset or IRQ 11. Software
enabled/disabled. Time interval is from 1 ~ 62 seconds. Jumperless
with run-time setup
VGA function
• Controller: C&T 69000/69030, supports CRT and 36-bit LCD
display types
• Display memory: 2 MB SDRAM built-in (optional 4 MB with
C&T 69030)
• Display resolution: Up to 1280 x 1024 @ 256 colors (16 million
colors @ 4 MB)
