42 PCA-6751 Series User's Manual
4.1 Introduction
The PCA-6751 Series has an onboard PCI flat panel/VGA interface.
The specifications and features are described as follows:
4.1.1 Chipset
The PCA-6751 Series uses a C&T 69000/69030 chipset for its
PCI/SVGA controller. It supports many popular LCD, EL, and gas
plasma flat panel displays and conventional analog CRT monitors.
The 6900/69030 VGA BIOS supports monochrome LCD, EL, color
TFT and STN LCD flat panel displays. In addition, it also supports
interlaced and non-interlaced analog monitors (color and mono-
chrome VGA) in high-resolution modes while maintaining complete
IBM VGA compatibility. Digital monitors (i.e. MDA, CGA, and
EGA) are NOT supported. Multiple frequency (multisync) monitors
are handled as if they were analog monitors.
4.1.2 Display memory
With on-board 2 MB display memory, the VGA controller can drive
CRT displays or color panel displays with resolutions up to 1024 x
768 at 64 K colors. The display memory can be expanded to 4 MB for
true-color resolution of 1024 x 768 with C&T 69030.
4.1.3 Display types
CRT and panel displays can be used simultaneously. The PCA-6751
Series can be set in one of three configurations: on a CRT, on a flat
panel display, or on both simultaneously. The system is initially set to
simultaneous display mode. The utility disks includes three *.COM
files in the subdirectory Utility\vga\ which can be used to
configure the display. In order to use these configuration programs,
type the file name and path at the DOS prompt.
CT.COM: Enables CRT display only
FP.COM: Enables panel display only
SM.COM: Enables both displays simultaneously
