76 PCA-6751 Series User's Manual
Table B-1: PCA-6751 Series PC/104 connectors (CN12)
Pin Signal (CN12)
Number Row A Row B Row C Row D
0 —— 0 V 0 V
1 IOCHCHK* 0 V SBHE* MEMCS16*
2 SD7 RESETDRV LA23 IOCS16*
3 SD6 +5 V LA22 IRQ10
4 SD5 IRQ9 LA21 IRQ11
5 SD4 -5 V LA20 IRQ12
6 SD3 DRQ2 LA19 IRQ15
7 SD2 -12 V LA18 IRQ14
8 SD1 ENDXFR* LA17 DACK0*
9 SD0 +12 V MEMR* DRQ0
10 IOCHRDY N/C MEMW* DACK5*
11 AEN SMEMW* SD8 DRQ5
12 SA19 SMEMR* SD9 DACK6*
13 SA18 IOW* SD10 DRQ6
14 SA17 IOR* SD11 DACK7*
15 SA16 DACK3* SD12 DRQ7
16 SA15 DRQ3 SD13 +5 V
17 SA14 DACK1* SD14 MASTER*
18 SA13 DRQ1 SD15 0 V
19 SA12 REFRESH* KEY 0 V
20 SA11 SYSCLK ——
21 SA10 IRQ7 ——
22 SA9 IRQ6 ——
23 SA8 IRQ5 ——
24 SA7 IRQ4 ——
25 SA6 IRQ3 ——
26 SA5 DACK2* ——
27 SA4 TC ——
28 SA3 BALE ——
29 SA2 +5 V ——
30 SA1 OSC ——
31 SA0 0 V ——
32 0 V 0 V ——
*active low
