UNO-2484G_V2 User Manual 2
1.1 Introduction
The UNO-2484G V2 is an embedded hardware-ready platform capable of shortening
development time. The system offers a wide range of networking interfaces to satisfy
the various needs of different applications. Equipped with the 11th Intel® Core™ i
processor, and 4GB or 8GB DDR4 RAM. It supports wide temperature range opera-
tion (-20 ~ 60°C/-4 ~ 140°F) and ample I/O - including 1 x GbE, 3 x 2.5 GbE, 2 x
mPCIe, 1 x M.2 B-key, 1 x M.2 M-key, 1 x HDMI, 1 x DP, 1 x USB2.0, 3 x USB 3.2, 1
x USB TypeC, and 4 x COM. It also supports 2 x Mini PCIe slot (PCIe/USB2.0 signal)
to enable expansion. An optional 2nd stack extension kit supports 2 x iDoor modules,
such as industrial Fieldbus, as well as I/O and peripheral modules.
The UNO-2484G V2 also has one M.2 B key, one M.2 M key for convenient expan-
sion. This allows the UNO-2484G V2 to be integrated with high speed Wi-Fi 6, 5G,
and NVMe SSD for high data-transmission efficiency With support for multiple drivers
and operating systems, including Windows 10, and Linux, users can easily integrate
applications on application-ready platforms in order to offer versatile functions for
diverse requirements.
1.2 Safety Precautions
Below are a few safety precautions for preventing injury when making connections. In
most cases, users can use a standard cable for connection.
Warning! Always disconnect the power cord from the chassis before manual han-
dling. Do not make any configuration changes when the power is on.
The sudden rush of power can damage sensitive electronic compo-
nents. Only experienced electronics personnel should open the chassis.
Warning! Toujours à la terre pour éliminer toute charge d'électricité statique avant
toucher UNO-2484G V2. Appareils électroniques modernes sont très
sensi- bles à charges d'électricité statique. Utilisez un bracelet antista-
tique à tout moment. Placez tous composants électroniques sur une
surface antistatique ou dans un statique-sac blindé.
Caution! Always ground yourself to remove any static electric charge before
touching UNO-2484G V2. Modern electronic devices are very sensitive
to static electric charges. Use a grounding wrist strap at all times. Place
all electronic components on a static-dissipative surface or in a static-
shielded bag.
Caution! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.
