87 UNO-2484G_V2 User Manual
Appendix A System Settings/Pin Assignments
A.10 GPIO Port (GPIO1)
The GPIO port can connect to DB9 connector for extension module.
Table A.12: GPIO Port (GPIO1)
Pin Signal Name
1 +5V
2 GPIO0
3 GPIO1
4 GPIO2
5 GPIO3
6 GPIO4
7 GPIO5
8 GPIO6
9 GPIO7
