Advantech UNO-2484G V2 User Manual

9 UNO-2484G_V2 User Manual
Chapter 2 Hardware Functionality
2.2.4 USB Connector
UNO-2484G V2 features 3 x USB ports for Rev. 3.2 specifications and 1 x USB
2.0port. The USB connectors support plug-and-play and hot-swap-ping functionality
for external devices. Additionally, this can be enabled/disabled in the BIOS menu.
(Please refer to User Manual- Appendix A.3 for pin assignments.)
2.2.5 HDMI Connector
The UNO-2484G V2 provides 1 x HDMI 1.4 connector for a high resolution interface,
3840 x 2160 @30Hz. (Please refer to User Manual- Appendix A.4 for pin assign-
ments.
2.2.6 DP Connector
The UNO-2372G V2 provides 1 x DP 1.4a connector for a high resolution interface,
4096x2304@60Hz. (Please refer to User Manual- Appendix A.4 for pin assign-
ments.)
2.2.7 RTC Battery
The UNO-2484G V2 is equipped with an RTC battery to ensure that the system clock
and BIOS settings are retained after power disconnections.
 Type: BR2032
 Output Voltage: 3 V
DC
2.2.8 Power Button/Power Management
Press the “PWR” button to power on/off the UNO-2484G V2 (ATX type). The system
can be configured to AT mode by adjusting the onboard switch to automatically turn
the system on when there is power input. (Refer to Appendix A.2 for more informa-
tion.)
2.2.9 Reset Button
Press the “Reset” button to activate the hardware reset function.
2.2.10 mPCIe Connector
The UNO-2484G V2 supports 2x mPCI Express mini card sockets. The mPCIE1 and
mPCIE2 interface is provided to support various mPCIe extension modules for
diverse applications. The UNO-2484G V2 double-stack model also supports the inte-
gration of iDoor modules (e.g., DI/O, COM, industrial fieldbus, etc.) via the MINI1
interface.
2.2.11 M.2 B-key Connector
There is one M.2 B Key connector for M.2 cards, labeled “M2_B1” on the mother
board. This M.2 interface is USB3.0 signal. It supports the installation of M.2 3042/
3052 module (w/ USB 3.0 Signal), and supports SATA signal for storage module.
(Please refer to user manual Appendix A.7 for pin assignments.)
Note! In addition to the M.2 B key (M2_B1) socket, the system features a
micro SIM slot for supporting 5G/LTE function. However, users are
required to install a 5G/LTE M.2 B key module to enable this function.
