83 UNO-2484G_V2 User Manual
Appendix A System Settings/Pin Assignments
Table A.7: M.2 B key Connector Pin Assignments
Pin Signal Name Pin Signal Name
1 GND 2 +V3.3_SB_NVME1
3 GND 4 +V3.3_SB_NVME1
5 PCIE_CPU_M2_M1_RX_N4 6 NC
7 PCIE_CPU_M2_M1_RX_P4 8 NC
9 GND 10 NC
11 PCIE_CPU_M2_M1_TX_N4 12 +V3.3_SB_NVME1
13 PCIE_CPU_M2_M1_TX_P4 14 +V3.3_SB_NVME1
15 GND 16 +V3.3_SB_NVME1
17 PCIE_CPU_M2_M1_RX_N3 18 +V3.3_SB_NVME1
19 PCIE_CPU_M2_M1_RX_P3 20 NC
21 GND 22 NC
23 PCIE_CPU_M2_M1_TX_N3 24 NC
25 PCIE_CPU_M2_M1_TX_P3 26 NC
27 GND 28 NC
29 PCIE_CPU_M2_M1_RX_N2 30 NC
31 PCIE_CPU_M2_M1_RX_P2 32 NC
33 GND 34 NC
35 PCIE_CPU_M2_M1_TX_N2 36 NC
37 PCIE_CPU_M2_M1_TX_P2 38 NC
39 GND 40 NC
41 PCIE_CPU_M2_M1_RX_N1 42 NC
43 PCIE_CPU_M2_M1_RX_P1 44 NC
45 GND 46 NC
47 PCIE_CPU_M2_M1_TX_N1 48 NC
49 PCIE_CPU_M2_M1_TX_P1 50 NC
51 GND 52 PCIE_REQ#
53 CLK100M_PCH_M2_M1_K_N 54 PCIE_WAKE#
55 CLK100M_PCH_M2_M1_K_P 56 NC
57 GND 58 NC
59 NC 60 NC
61 NC 62 NC
63 NC 64 NC
65 NC 66 NC
67 NC 68 SUSCLK
69 PEDET 70 +V3.3_SB_NVME1
71 GND 72 +V3.3_SB_NVME1
73 GND 74 +V3.3_SB_NVME1
75 GND
