Advantech WISE-4050/LAN User Manual

95 WISE-4000 User Manual
Appendix A I/O Modbus Mapping Table
Address (4X):
00131 0
High Alarm Flag
Read
00132 1 Read
00133 2 Read
00134 3 Read
00135 Average Ch 0~3 Read
00141 0
Low Alarm Flag
Read
00142 1 Read
00143 2 Read
00144 3 Read
00145 Average Ch 0~3 Read
Address (4X) Channel Description Attribute
40211 Module Name 1 Read
40212 Module Name 2 Read
40221 All AI AI Channel Enabled Read/Write
40303 All DO DO Value Read/Write
40001 0
AI Value
Read
40002 1 Read
40003 2 Read
40004 3 Read
40005 Average Ch 0~3 Read
40009-40010 0
Pulse Output
Low Level Width
Read/Write
40011~40012 1 Read/Write
40013~40014 2 Read/Write
40015~40016 3 Read/Write
40017-40018 0
Pulse Output
High Level Width
Read/Write
40019~40020 1 Read/Write
40021~40022 2 Read/Write
40023~40024 3 Read/Write
40025-40026 0
Pulse Output Number
(0 for continuous output)
Read/Write
40027~40028 1 Read/Write
40029~40030 2 Read/Write
40031~40032 3 Read/Write
