A.3 WISE-4050/LAN Modbus Mapping Table
Address 0X Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00003 2 Read
00004 3 Read
00017 0
DO Value
Read/Write
00018 1 Read/Write
00019 2 Read/Write
00020 3 Read/Write
00033 0
Counter Status
(0: stop
1: start)
Read/Write
00034 1 Read/Write
00035 2 Read/Write
00036 3 Read/Write
00037 0
Clear Counter
(1: write to clear value)
Write
00038 1 Write
00039 2 Write
00040 3 Write
00041 0
Clear Overflow
(1: counter overflow,
auto set to 0 after read)
Read/Write
00042 1 Read/Write
00043 2 Read/Write
00044 3 Read/Write
00045 0
DI Latch Status
(1: DI latched,
0: write to clear latch)
Read/Write
00046 1 Read/Write
00047 2 Read/Write
00048 3 Read/Write
Address 4X Channel Description Attribute
40211 - Module Name 1 Read
40212 - Module Name 2 Read
40301 All DI DI Value Read
40303 All DO DO Value Read/Write
40001~40002 0
Counter/Frequency
Value
Read
40003~40004 1 Read
40005~40006 2 Read
40007~40008 3 Read

Advantech WISE-4050/LAN Specifications

General

Brand	Advantech
Model	WISE-4050/LAN
Category	I/O Systems
Language	English
