WISE-4000 User Manual 44
4.1 Connection
1. Plug a DC power source into the +Vs, -Vs pin of WISE module to turn the power
on, or plug in the USB power cable for the WISE-4012E.
2. For WISE-4000/LAN Series, connect your computer to Ethernet port of WISE
module with RJ-45 cross-over Ethernet cable, and configure the IP address of
your computer as same IP domain as default IP address of module: 10.0.0.1. Or
the wireless router can be used for configure the WISE-4000/LAN Series by
mobile devices or computer with wireless adapter.
3. For WISE-4000 Wireless Series, the default operation mode in normal mode is
AP Mode, or you can change position 1 of SW1 to OFF as in Section 1.5, to set-
ting the module as Initial Mode, then module must be AP Mode. Now the mod-
ule can be searched by mobile devices or wireless adapter of computer with
SSID: WISE-4xxx_MACAddress. Click the SSID to connect the module in AP
Mode, WISE module will auto assign the IP address for mobile devices or com-
puter.
4.2 Configure WISE Using the Web Interface
4.2.1 System Requirements
WISE-4000 module is developed by public HTML 5 base, but for detailed indication
and data transmission mode may be different on Web page of the operating system.
For mobile devices, the minimum requirement of web browsers as below:
Safari 6 in Apple iOS
Web Browser in Google Android 4.0 (Ice Cream Sandwich)
Chrome in Google Android 4.0 (Ice Cream Sandwich)
For PC platforms, the minimum requirement of web browsers as below:
Internet Explorer (version 11)
Google Chrome (version 30)
Mozilla Firefox (version 25)
Mobile Browse Chrome Android Safari
Configuration Y Y Y
File Upload N N N
Data Log Chart Y Y Y
Data Log Export N N N
Mobile Browse Chrome Firefox Safari IE11 IE10 IE9
Configuration Y Y Y Y Y Y
File Upload Y Y N Y N N
Data Log Chart Y Y Y Y Y N
Data Log Export Y Y N N N N
