Advantech WISE-4050/LAN - Using a Browser to Configure the Module

WISE-4000 User Manual 46
4.2.6 Using a Browser to Configure the Module
 Configure URL: http://IP_address/config
 Default URL:
WISE-4000/LAN Series: http://10.0.0.1/config
WISE-4000 Wireless Series: http://192.168.1.1/config
 Configuration Steps
Login Web Configuration Page
1. Wirelessly connect your smart phone
to your local Ethernet network and
open the browser of your smart
phone.
2. Enter IP address of module with "/
config", for example, the default URL:
http://10.0.0.1/config or http://
192.168.1.1/config
3. Then you will see the login page,
please enter the account and pass-
word, then click Login button
4. After login you will see the configura-
tion web page
5. Scroll down the tab, you can change
the login user here
6. Click the button on the top, you can
switch to other pages
